Busbar Automatic Production Machine Automatic Busbar Assembly Line
Automatic busbar assembly line has four-piece type and two-piece type. Busbar can be assembled automatically with rivets or bolts according to the design.
The automatic assembly machine can realize automatic assembly of busbar. It reduces manpower and improves the product quality and working efficiency. The working principle is to recognize the busbar type and adjust all the parameters of the machine automatically by scanning the bar code. With the interconnection of PLC, network, touch screen and IPC etc, it can also connect with ERP and automatic inspection machine.
The automatic assembly machine has self checking functions, including self diagnosing each input and output signal, preventing failures and counting the machine’s OEE (comprehensive utilization rate) for the big data analysis in the future.
Kiande Specialized in manufacturing and customizing busbar production machines including Busbar Automatic Production Line, Automatic Assembly Machine, Automatic Busbar Assembly Line, Semi-Automatic Assembly Line, Busbar Manual Assembly Machine, Two-Piece Manual Assembly Machine, Busway System Inspection Line, Busbar Manual Inspection Machine, Busway System Packaging Machine, Busbar Manual Packing Machine, Busbar Profile Cutting Machine, Distribution Board Production Line, Switchgear Production Line, Distribution Box Switch Box Production Line, Switchboard Assembly Line...
| No. | Parameters |
| Model | KD-WTGZ-SP/CZ-1500 |
| Max. Size of X/Y Axis | 1500mm |
| Clamping Fixtures Nos | 3 pieces |
| Elbow Type | Horizontal type, vertical type |
| Power | 380~415VAC 50~60Hz 1.5kW |
| Air Source | 0.6MPa |
| Equipment Dimension | L1800mm*W1800mm*H900mm |
"Busbar Trunking System Market Size By Insulation (Sandwich, Air-insulated), By Power Rating (Lighting, Low, Medium, High), By Conductor (Copper, Aluminum), By Application (Industrial {Power, Oil & Gas, Process, Transportation, Manufacturing}, Commercial {Education, Retail, Hospitality, Societies, Healthcare, Others}, Utilities), Industry Analysis Report, Regional Outlook (U.S., Canada, Mexico,
UK, Germany, Italy, Spain, France, Sweden, Austria, Netherlands, Denmark, Finland, Norway, Russia, China, India, Japan, Australia, South Korea, Indonesia, Philippines, Thailand, Malaysia, Singapore, New Zealand, Saudi Arabia, UAE, Iran, Qatar, Kuwait, Oman, Turkey, Bahrain, South Africa, Egypt, Nigeria, Algeria, Brazil, Argentina, Chile), Application Potential, Competitive Market Share & Forecast, 2019– 2025
FAQ
Q1: Are you a factory or trading company?
A1: Our factory located in Zhengjiang city which is specialized in busbar assembly equipment and switchgear assembly equipment such as busbar assembly system, busbar testing machine, busbar wrapping machine and busbar accessores. Our sales office located in Suzhou city which traffic is more convinent.
Q2: Where is your factory location? How can I visit there?
A2: Our factory is located in Jiangsu, China, welcome to visit us at any time. You can take the plane to Shanghai and then take the highway to Changzhou Bei Station(1 hour), then we will pick u up.
Product Tags:
|
|
Horizontal Elbow Busbar Assembly Line Automatic Production Images
|
